Description
The JAC0524LFP-R (0600-61) 24v – 5 Amp Battery Charger is a Lithium (LiFePO4) Charger.
JAC0524LFP-R
178 x 88 x 47 mm
0.8 kg
AC Input:
Input Voltage: 115 VAC, 50/60 Hz
Input Current Max: 3 Amps
Single Phase
Input Receptacle: IEC C14
DC Output:
Output Voltage - Nominal: 24 VDC (25.6 LiFePO4)
Output Voltage: 28.8 VDC
Float Voltage: 26.6 VDC
Max DC Current: 5 Amps
Battery Type: Lithium Iron Phosphate (LiFePO4)
3 Stage Charging Profile: CC/CV
Load Sensing, Minimum Voltage: 8 Volts
Features:
Cooling Fan
Reverse Polarity Protection
High Energy Efficiency (UEC, BC)
Voltage Limited
Current Limited
Over Voltage Protection
Over Temperature Protection
Short Circuit Protection
Aluminum Case
Mounting Flanges
On / Off Switch
Detachable AC Cord, 5 ft (NEMA 5-15/IEC C13)
Certifications:
Safety – CE
DOE UEC Title 20, 10 CR, Part 430
California BC Energy Efficiency Compliant
LED Lights:
Left – Red: Power On
Right- Amber (Fan): Charging
Right – Green (No Fan): Full Charge / Float Mode
Warranty Information
Additional Information
Charger Voltage: |
24 Volt |
Charger Amperage: |
5 Amp |
Charger Plug: |
Rings |
